9.4

Actual-current sensing module

Z = K91
Replacement parts, Order No. for module: 6SE7028-8FC85-0OA0
Unit Jumper
Size
E
B and C
keine
Table 9.6 Jumpers for actual-current sensing module
The compliance voltage at the rated output current is 10V.
The transformation ratio of the current transformers is 2000 : 1
Source resistance R
i total
When measuring equipment is connected to the unit, the effective load impedance and thus the voltage will
vary in accordance with the internal resistance of the equipment.
For the lowest rated output current of Type E units, 142A, jumpers J1 to J4 should be closed and J5 to J14
open. For the maximum rated output current of 605A, all jumpers (J1 to J14) should be closed.
Example: For a unit with a rated output current of 222A, jumpers J7 to J14 should be open.
Replacement units are supplied with all jumpers closed (J1 to J14). Before start-up the unit, therefore, the
jumpers should be positioned as appropriate to the rated output current (see rating plate) and accordance
with Table 9.6.
Siemens AG 6SE7087-6AE85-0AA0
Common Rectifier Operating instructions
for one current transformer: 6SY7010-5AA02
I
rated output
[A]
J14 605
J13 536
J12 463
J11 420
J10 375
J9 354
J8 270
J7 235
J6 222
J5 173
J4 142
J3 94
J2 86
J1 72
41
as per table.
R
i total
[Ohm]
33,222
37,507
43,432
47,886
53,647
56,849
74,557
85,677
90,720
116,421
141,887
214,464
234,523
280,230
492,381
NOTE
Options
9-5
