Siemens SIMOVERT Master Drives Betriebsanleitung Seite 125

02.04
Common 6SE70..-.....-0RA0 31-7EE85 33-2EE85 36-1EE85
rectifier
Rated voltage, rated frequency, rated current, rated power
Rated voltage
Input U
n
Output U
dn
Rated frequency f
n
Input
Output
Rated current I
n
Input (rms value) AC
Output (average) DC
Load class II acc. EN 60146-1-1
Rated output current average
Base load duration
Excess output current
average
Excess current duration
Losses, cooling, power factor
Power factor
Mains cosϕ
1N
Power dissipation
− Maximum
Cooling air requirement
Sound pressure level, dimensions, weight
Sound pressure level of fan
Size
Width
Height
Depth
− Standard
− Option
Weight app.
Siemens AG 6SE7087-6AE85-0AA0
Common Rectifier Operating instructions
V
Hz
A
2x144 2x278
2x166 2x320
A 151
s
A 226
s
kW 0.80 1.36
3
m /s 0.2
dB(A) 75
E
mm 269
mm 1050 1050
mm 340
mm 350
kg 35
3 AC 380V -15% to 480V +10%
DC 510V –15% to 650V +10%
46 to 64
D.C.
2x526
2x605
291 550
240
435 823
60
1
2.60
0.2 0.2
75 75
E E
269 269
1050
340 340
350 350
35 44
Technical data
14-5
ENGLISH
