Siemens SIMOVERT Master Drives Betriebsanleitung Seite 113

02.04
Desig- Description
nation
LBA Local bus adapter for the electronics box. This is
required for installing T300, CB1, TSY, SCB1 and
SCB2
ADB Adapter board for small boards. Precondition for fitting
CBC and CBP
T100 Technology board
T300 Technology board for controlling technological
processes
SCB1 Serial communications board with fiber-optic cable for
serial I/O system and peer-to-peer connection
SCB2 Serial communications board for peer-to-peer
connection and USS protocol via RS485
Use of the serial interface with USS protocol
CB1 Communications board with interface for SINEC- L2-
DP, (Profibus)
Use of the PROFIBUS DP interface
CB2 Communications board with interface for CAN protocol
CBP Communications board with interface for SINEC-L2-DP,
(Profibus) (small-format board; must be plugged onto
the ADB on the right-hand side or below)
CBC Communications board with interface for CAN protocol
(small-format board; must be plugged onto the ADB on
the right-hand side or below)
Table 9.3 Option boards and bus adapter
Slot in the electronics box
Left Slot 1 (PSR)
Middle Slot 3 (options)
Right Slot 2 (options)
Table 9.4 Slots in the electronics box
Siemens AG 6SE7087-6AE85-0AA0
Common Rectifier Operating instructions
Board
description
Board
Board
description
Board
description
Board
description
Board
description
Application
description
Board
description
Application
description
Board
Description
Board
Board
Boards
PSR
CB1 / SCB1 / SCB2 / CBC (with ADB) / CBP (with ADB)
CB1 / CB2 / CBP (with ADB) / CBC (with ADB) / SCB1 /
SCB2 / T100 / T300
Options
Order No.
6SE7090-0XX84-4HA0
6SE7080-0CX84-4HA0
6SE7090-0XX87-0BB0
6SE7080-0CX87-0BB0
6SE7090-0XX84-0AH0
6SE7080-0CX84-0AH0
6SE7090-0XX84-0BC0
6SE7080-0CX84-0BC0
6SE7090-0XX84-0BD0
6SE7080-0CX84-0BD0
6SE7087-6CX87-4KB0
6SE7090-0XX84-0AK0
6SE7087-0CX84-0AK0
6SE7087-6CX87-0AK0
6SE7090-0XX84-0AE0
6SE7087-6CX84-0AK0
6SE7090-0XX84-0FF0
6SE7090-0XX84-0FG0
9-3
