Installation; Wall Mounting - Kemper KHS Mini MASTER 2.1 Montage- Und Bedienungsanleitung

2

Installation

Allow only certified electricians to assemble and install electrical
equipment. Danger of fatal electric shock.
Rigid leads must form a loop for wiring so that there is no pressure on the
terminals and the housing closes without resistance.
2.1

Wall mounting

Ill. 1 - Illustration of the mounting holes for wall installation
Please pay attention to the disturbance space when installing the Control
System.
Left-hand side: Serial number of the KHS Mini Control System
Right-hand side: USB-slot
© www.kemper-olpe.de – 09.2020 / K410068602008-00 – 93 / 259
Disturbance
space
