Configuration

2
Ill.: 6.6.3: Selection dialogue „Upload configuration file"
Ill.: 6.6.4: Selection dialogue „Back up configuration file"
After successfully configuring your Control System, you are recommended
to save the configuration as a backup file. If the KHS Mini Control System
-MASTER 2.1- is defective, it can be quickly replaced and the configurati-
on can be read in. This saves having to configure everything again.
© www.kemper-olpe.de – 09.2020 / K410068602008-00 – 163 / 259
Loading a configuration from a file
The „Configuration" function can be
used to install an existing configuration
in the connected KHS Mini Control Sys-
tem. To do this, click the Search button.
The CFG file opens in the window that
then opens, see Fig. 6.6.3. After the
LOAD CONFIGURATION FROM FILE
button has been clicked, the selected
configuration is then loaded into the
Control System.
The network and e-mail settings can
only be loaded when the configuration
is loaded using a USB stick. They are
not imported when the configuration
is loaded using the web server.
Backing up the configuration
You can use the „Configuration"
function to backup parameterised
configurations of the connected KHS
Mini Control System to your PC. To do
this, click the WRITE CONFIGURATION
TO FILE button. In this window, see Fig.
6.6.4, you can back up the CFG file to
the desired folder on your PC.
