EN
Define times
After a line type has been selected,
define the times. A starting and stop-
ping time has to be specified for the
„Release" line type. Furthermore, the
desired weekdays can be selected from
a dropdown list. Click in the box of the
weekday in question to activate it with
a check mark.
Configuration of measurement (datalogging)
Select type
After a line has been added using ADD
LINE, the line type is selected.
The KHS Mini Control System in this
sample project is connected to a KHS
Control Plus flow measurement valve.
To record the flow measurement valve
measurement data at the same time,
the „Datalogging" line type must be
selected from a drop-down list.
