Serial number KHS HS2 Hygiene flushing box
Serial number of KHS Flush Box PRO on type plate

Main view

When all the devices have been added,
they are displayed in the main view, as
3.1.2.3
In the „Device settings" submenu, the
individual Control System are logically
assigned to the integrated actuators and

Steuerungstyp

B valve
A valve
C valve
Safety device
Only measurement
108 / 259 – K410068602008-00 / 09.2020 – © www.kemper-olpe.de

Device settings

Beschreibung
Terminal flushing valve, with several A valves hydraulically preconnected.
Depending on the type of valve, A valves switch the water exchange of a
line or set up the hydraulic balacing in a cold water circulation
Terminal flushing valve for one line.
Valve which protects a distribution line.
Slave for the acquisition and long-term monitoring of sensor values.
shown below. The individual devices can
then be configured in Device settings.
Check to see if the CAN bus icon can always be
seen on the main screen for each connected device
and if the LEDs light up green on all system controls
and hygiene flushing boxes. Only then has a proper
connection been established.
sensors. The valve control type is also
determined.
