Figure 2: Lifting eye. Generic Compit 901 is shown.
8. Lift the unit.
9. Put the unit on the pallet in an upright position.
CAUTION: Crush Hazard
Make sure that the unit cannot roll or fall over and injure people or damage
property.
2.8 Long-term storage
Long-term storage outdoors must not exceed four months. Make sure that the unit is covered with a tarpaulin or
similar.

3 Product Description

3.1 Products included
This document includes the following products:
Product denomina-
tion
Compit 901H
Compit 901P
3.2 Design
The pump station unit is delivered pre-assembled for the installation of pipes, from the house and to the force
main, and for the connection of the power supply. It can function, for example, as a wastewater collection tank
for a single house with a connection to natural infiltration, or in a branched pressure sewer system.
Pump station with anchoring ring (foot)
The unit is designed to prevent it from being forced up in normal types of ground.
Depending on the subsoil water table, an anchoring ring can be needed.
3.2.1 Anchoring ring (foot)
Installation type Installation type description
H Stationary wet installation suspended from the discharge pipe.
The quick connection joint has an integrated non-return valve.
P Semipermanent wet well installation. The pump is installed be-
tween guide-bars on a discharge connection.
