For pump weights, see the dimensional drawing of the pump.
A complete preassembled pumping station for two pump including anchoring ring, Class B cover, and the lon-
gest extension, can weigh up to 277 kg (611 lb). This weight does not include the pumps.
Table 1: Main unit
Type Discharge connection
Material
901 H PPA
901 H Cast iron
901 H Cast iron
901 P Cast iron
901 P Cast iron
Table 2: Other items
Item
Anchoring ring (foot)
Cover
Cover
Cover
Extension
Extension
Maximum allowed pump weight
55 kg
3.2.7 Materials
The unit is rotomoulded polyethylene, PE.
3.2.8 External loads
• The maximum load rating for the plastic access cover is 1 kg/cm
• A concrete access cover Class A is applicable for any location where it is subjected only to loads from pe-
destrians or pedal cyclists.
• A concrete access cover Class B is applicable for pedestrian areas, car parks, or car parking decks.
• A concrete access cover Class D is applicable for carriage ways of roads, hard shoulders, and parking areas
for all types of road vehicles.
NOTICE:
Only pump stations which are designed for Class D can be used in Class D
environments.
3.2.9 Pumping station identification
At delivery, the color of the outlet end cap shows what type of station it is.
End cap color Installation
Yellow H
Transparent H
Red H
Green P
Gray P
3.3 Pump versions
Depending on the type of unit, different pumps can be used.
Number of pumps
The pump is not includ-
ed
1
1
2
1
1
Description
–
Class A
Class B
Plastic
750 mm (29.5 in)
1400 mm (55.1 in)
Number of pumps
One pump
Two pumps
One pump
One pump
One pump
Discharge connection
DN32
DN50
DN50
DN32
DN50
Material
PE
Concrete and steel
Concrete and steel
PE
PE
PE
2
but no heavier than 120 kg (264.6 lb).
Discharge connection characteristics
Cast iron parts
Cast iron parts
High performance polyamide (HPPA) parts
DN32
DN50
en - Original instructions
Weight, kg (lb)
105 (231)
115 (254)
129 (284)
108 (238)
109 (240)
Weight, kg (lb)
16 (35)
78 (172)
107 (236)
5 (11)
14 (31)
25 (55)
