Xylem FLYGT Compit 901 Installation Seite 16

en - Original instructions
Figure 3: Dimensional drawing. Unit: mm
Access Cover
Plastic
Class A
Class B
Figure 4: Location of outlet and inlets
4
6
2
3
3.2.6 Weight
16
3
5
1
4
1202
1286
Dimension A, mm
72
33
78
1
3
1. Inlet: DN 150
2. Inlet: DN 100
3. Inlet: DN 150
4. Inlet: DN 100
5. Outlet: DN 32 or
DN 50
6. Cable duct or vent-
ing: DN 100
2
