en - Original instructions
• The minimum height (contact your local sales and service representative for information) between the lifting
hook and the floor must be sufficient to lift the unit.
• The lifting equipment must be able to hoist the unit straight up and down, preferably without the need for
resetting the lifting hook.
• The lifting equipment must be securely anchored and in good condition.
• The lifting equipment must support weight of the entire assembly and must only be used by authorized per-
sonnel.
• Two sets of lifting equipment must be used to lift the unit for repair work.
• The lifting equipment must not be oversized.
CAUTION: Crush Hazard
Over-dimensioned lifting equipment can lead to injury. A site-specific risk
analysis must be done.
Separate handling of pump and unit
The unit and the pump are delivered separately. Never install a pump prior to lifting the unit.
Empty the unit before lifting
The unit must be emptied of liquid before lifting.
2.5 Remove from the pallet: Unit delivered right-side up
This section is applicable for units that are delivered with a plastic access cover. Units with a plastic access cov-
er are delivered in a vertical position, standing right-side up on the delivery pallet.
1. Unload the unit from the truck and put it carefully on a rigid, horizontal surface.
2. Attach a sling to the lifting eye.
Figure 1: Lifting eyes
3. Connect the other end of the lifting strap to the lifting equipment.
4. Raise the lifting hook until the lifting sling is taut.
5. Cut the straps which secure the pump station to the pallet.
6. Lift the unit straight up.
The unit may jolt or sway near the end of the lifting operation.
WARNING: Crush Hazard
Always lift the unit by its designated lifting points.
