Xylem FLYGT Compit 901 Installation Seite 14

en - Original instructions
1
1. A foot is needed when the ground water table is high.
2. If the ground water table is lower than 800 mm (31.5 in) below the surface, then the foot is not needed.
3.2.2 Parts
Items included in the pumping station
• Tank
• Access cover
PE, Class A, Class B
• Internal pipes and valves
• Anchoring ring (foot)
Depending on version
• Operating handle with chain for shutoff valve
The following figures show examples of H- and P-installations.
14
2
Items that are ordered separately, or provided lo-
cally
• Access cover Class D
This cover is constructed on site
• Pump
• Elbow pipe, if needed for the pump
• Discharge connection
• Level sensor
• Control panel
