Operation
Step 3
If the sensor face and the target are mismatched (not parallel), there will be a loss in the range and a shift in
the zero point depending on the tilt.
Curved target surfaces cause linearity reductions if the distance between the sensor and the target is small.
Linearity and sensitivity deviations also occur with a too small target dimensions.
Fig. 7
Controller with option I (current output):
The values
-
-
capaNCDT 6100
Repeat steps 1 and 2 about three times until a stable potentiometer setting results.
Replace the housing cover.
10 V
Output
voltage
0 V
1
0 % Measuring range
Sensor
Target
Calibration steps
4 mA (start of measuring range) and
20 mA (end of measuring range) are set for systems with current output.
2
100 %
1 = Start of measuring range
2 = End of measuring range
