E11
COLLIMATOR SELECTION NOT CONSISTENT
E14
GENERIC GENERATOR FAULT
E15
E17
DEVICE OVERHEATED
HEAD RELEASED
E18
SUPPLY VOLTAGE TOO HIGH/LOW
E19
E30
INTERNAL ADJUSTMENT PROBLEM
E31
REMOTE CONTROL ERROR
E32
E33
NO POWER SUPPLIED TO X-RAY GENERATOR
As regards the other error codes, CONTACT the technical service department.

7. Routine maintenance

ATTENTION!
Any technical maintenance work required must be carried out by qualified personnel or by a specialised technician authorised by the
manufacturer.
It is the user's responsibility to check that routine maintenance is carried out by an authorised technician at least every 2 years.
The maintenance methods are specified in the Technical Service Manual possessed by the Authorised Technicians.

8. Cleaning and disinfection

The x-ray unit may be a source of infection passed from one patient to another if it is not cleaned properly. For this reason it should be disinfected
on the outside every day after use.
If digital X-ray sensors are used make sure they are always used with disposable hygienic covers. When disinfecting the x-ray unit use soft
disposable paper and avoid using corrosive substances or immersing the unit in liquids.
To avoid damaging the plastic materials use products containing:
• Ethanole 96%:
Concentration: maximum 30 g per 100 g of disinfectant.
• Propanole:
Concentration: maximum 20 g per 100 g of disinfectant.
• Combination of ethanole and propanole:
Concentration: the combination of the two should be maximum 40 g per 100 g of disinfectant.
Compatibility tests between plastics and the following products have been carried out with no negative consequences:
• Incidin Spezial (Henkel Ecolab).
• Omnizid (Omnident)
• Plastisept ( ALPRO ) (not tuberculocide as not an alcohol-based disinfectant)
• RelyOn Virkosept ( DuPont).
• Green & Clean SK ( Metasys ) (not tuberculocide as not an alcohol-based disinfectant)
ATTENTION!
• Do not use products containing isopropyl alcohol (2-propanol, iso-propanol).
• Do not use products that contain sodium hypochlorite (bleach).
• Do not use cleaners that contain phenol.
• Do not spray the selected products directly on the surfaces.
• Never combine products with each other or with liquids other than the products listed above.
• All products must be used as directed by the manufacturer.
Cleaning and disinfecting instructions.
Use soft disposable paper towels or sterile gauze to clean and disinfect.
Do not use sponges or in any case, any material that can be reused.
ATTENTION!
• Shut off the unit prior to clean and disinfecting the external parts.
• Never lubricate the pivot point of the x-ray cone as proper operation of the locking system may be compromised.
• All material used to clean and disinfect must be thrown away.
16 16 OPERATING INSTRUCTIONS
After turning the rectangular collimator on or off, wait a few
seconds to allow the icon on the handheld to be updated.
Contact technical service.
WAIT APPROXIMATELY 15 MINUTES FOR AUTOMATIC
SYSTEM RESET
CHECK THE SUPPLY SYSTEM.
IF THE PROBLEM PERSISTS, CALL TECHNICAL
SUPPORT.
REPEAT THE X-RAY. IF THE PROBLEM PERSISTS,
CALL TECHNICAL SUPPORT.
REDUCE THE DISTANCE BETWEEN THE REMOTE
CONTROL AND X-RAY HEAD AND THEN REPEAT THE
X-RAY. FOLLOW THE INFORMATION GIVEN ON HOW
TO PROPERLY USE THE HAND HELD'S ANTENNA.
X-ray generator or arm cord may be faulty. Contact
technical support service..
