2. PRODUCT

2.1 The charging station

On page 3 of this manual, you will find the images of the Eve Single Pro-line DE product line. In this chapter, you will find
more information on the contents of these charging stations and how they can be used to charge your vehicle.
Eve Single Pro-line DE (page 3)
Outside
Colour display
1
RFID pass reader
2
Type 2 socket or plug holder
3
Energy meter viewing window
4
Inside
UTP (Ethernet) connector
5
RJ11 connector
6
SIM card holder
7
Terminal block for the power cable
8
Clamps for outbound charging cable (model without socket outlet)
9
a. Screws for wall-mounting frame
10
b. Screws for wall-mounting frame with earth connection
10
Screws for front cover
11
Eichrecht compliant electricity meter
12
Bottom
Identification label
13
Cable gland for the power cable
14
Cable gland for charging cable
15
Wall-mounting frame
16
Grommet for UTP cable/Ethernet cable
17
Grommet for P1 cable
18
Identification label
The identification label
• Model, production date and serial number.
• Technical specification number.
• Article number and maximum charging current.
When contacting Alfen, always have your serial number available to facilitate quick support.
8
found on the bottom of the charging station specifies elements such as:
13
