3. ASSEMBLY AND CONNECTING

3.2 Assembly and installation requirements

See the table in paragraphs 2.6.10 and 2.6.11 for
the safety options and necessary cable diameters
for a proper connection.
Ensure that the following requirements for installing the
Eve Single Pro-line DE have been met:
• The cable trajectory from the main distribution panel to
the Eve Single Pro-line DE must be secured against
short-circuiting and overcurrent with:
- a B- or C-type circuit breaker (or other, in accordance
with local standards and regulations), or
- gG-type fuses (or other, in accordance with local
standards and regulations).
• The cable trajectory must be equipped with 30mA fault
current protection with a type A or B residual-current
device (RCD). The RCD must be capable of withstanding
the maximum current the charging station can process
(20A or 40A)
• The cable trajectory and the charging station are part of
a TN-S system; the equipment must be earthed at the
main distributor or with an earth pin (TT). In an energy
grid without neutral make sure that the station is
properly earthed, one of the phases is used as a neutral
and that the voltage-levels of par. 2.6.10 are complied
with.
• The cable trajectory must be installed in accordance
with the usual local professional standards.
REMARK
The installation and cables should be installed to match
the maximum charging current to the input of the charging
station. This should assume continuous load. The cable
diameters stated in this manual are indicative. The installer
is always responsible for choosing the right cable diameter
and complying with the relevant standards and legislation.
REMARK
Protect Alfen products installed in public areas and car park
sites from mechanical impact and/or collisions which can
cause damage to the equipment.
While selecting a location to install the Eve Single Pro-line
DE, the following criteria must be taken into account:
• Never install in a potentially explosive atmosphere.
• Never install in areas prone to flooding without imple-
menting compensatory measures.
• Always fully comply with local technical requirements
and safety regulations.
• An on-site connection is created that complies with the
specifications in paragraphs 2.6.10 and 2.6.11.
• The installation site must have a levelled and solid
foundation.
20
• A temperature difference within 24 hours < 35 °C.
• The recommended installation height is 80 - 120 cm
from the ground to the bottom of the casing.
• The charging port on the vehicle needs to be easy to
reach with the (attached) charging cable.
• Ensure that the charging station is placed at a location
where users can use their charging cable (approx. 5 -
8 metres) without placing any tension on the cable.
• Prevent other drivers from being able to drive over
the cable.
• Prevent pedestrians from tripping over cables.

3.3 Mechanical installation

Use the following tools and equipment to install the Eve
Single Pro-line DE:
• Spirit level;
• Impact drill with 8mm stone drill bit;
• Cross-head screwdriver (PZ2);
• Cross-head screwdriver (PH4);
• Wire stripper;
• Torx T20 wrench (included);
• 4x 5 x 50mm screw (included);
• 6x M4 x 8mm screw (included);
• 4x plugs 4.5 - 5mm (included);
• 4x M8 washer (included);
• 4x M8 nut (included)
Mounting post: Install the post with the concrete base
or metal base (accessory):
1. Dig a hole of approx. 50x50cm with a depth of 65cm.
2. Place the concrete or metal base in this hole.
3. Attach the post on the base with four threaded
bolts M10x25 mm and the corresponding rings (ref.
image on the cover or the base's installation
manual).
4. Attach the mounting block with two screw bolts
M10x25 mm.
5. Attach the charging station on the post with two
screw threads M10x25 mm.
6. Attach the ground wire on the post with M4x12 mm
screws and an M4 washer.
7. Guide the ground wire through the concrete base
and the base to the charging station.
8. Refill the hole in which the base is placed and
level the surface.
9. Once completed, cover the area with a levelled
protection such as tiles.
