Package contents
1 x
Eve Single Pro-line DE
- With Socket
- With Fixed cable
4 x 4 x
Screw Plug 4.5-5
5 x 50mm 8mm

3.1 Installing and connecting

Carefully read these instructions prior to installing the
charging station. Alfen ICU B.V. is not liable for any
consequential damage caused by usage of this manual.
REMARK
The installation must be carried out by a qualifi ed
professional who has read this manual and works in
compliance with IEC 60364 standards. Neglecting this
may lead to severe injuries or hazardous situations while
working with electricity.
REMARK
This work may not be carried out during rain or if air
humidity exceeds 95%.
REMARK
A charging station must always be installed on a dedicated
power circuit.
DANGER!
Hazard of fatal injury if installed incorrectly!
Non-compliance with the installation and environment
requirements may lead to hazardous situations while
working with electricity.
Eve Single Pro-line DE manual | Version 1.0 | February 2020
Contents of the charging station package: Alfen Eve Single Pro-line DE
installation manual, wall-mounting frame, installation supplies and RFID charge
passes (depending on options selected)
1 x 1 x
Wall-mounting This manual
frame
4 x 4 x
M8 nut M8 washer

3. ASSEMBLY AND CONNECTING

1 x
Quick Installation
Guide
6 x 1 x
Torx screw Reduction
M4 x 8mm fi tting
M32 x 1.5
DANGER!
The charging station contains electric components that
may still contain electrical charge after being disconnect-
ed. Wait at least 10 seconds after disconnection before
commencing work.
WARNING
The adaptors or conversion adaptors are not allowed to be
used.
WARNING
Cord extension sets are not allowed to be used.
DANGER!
The electric system must be entirely disconnected from
every power source prior to performing installation or
maintenance work!
REMARK
The conditions at the specifi c location may infl uence the
installation requirements.
,
TM
1 x 2 x
M25 x 1.5 M25 x 1.5
(For model (For model with
with socket) fi xed cable)
1 x 1 x
Filler washer for Torx T20
the cable gland wrench
19
