2. PRODUCT

2.6.5 Communications security

SIM card
Central System authentication
EVSE authentication
Remote console access (SSH, telnet)
Diagnostic files
Firmware update files
EVSE Interal Flash
Root certificate
For more information on the implementation of information security in Alfen Charging Equipment, you can contact
ace.salessupport@alfen.com
2.6.6 General product specifications
Number of outlets
Types of outlets
Supported power systems
Nominal output voltage (+/- 10%)
Maximum design current
Maximum design power
Connection clamps
Activation relay
Residual current protection
Overcurrent protection
Available in- and outputs
NOTICE!
Alfen Eve Single charge stations contain a 6mA DC detector that protects the earth leakage circuit breaker against DC leak-
age currents. The DC detector prevents type A earth leakage circuit breakers from becoming 'blind' to dangerous leakage
currents. The charging station will respond well in advance of any dangerous situation (6mA vs 30mA). Instead of jumping
the earth leakage circuit breakers, the charging station will stop the charging process in a controlled manner if leakage
currents are detected. After a time-out, and provided that the 6mA leakage current is no longer measured, the charging
process will be restarted. Three restarts are possible before the charging process is stopped permanently and an error code
is displayed. This function does not, nor will it ever, replace an earth leakage circuit breaker and cannot be tested as such
by the installer. If legislation and regulations require a type B earth leakage circuit breaker to be installed, regardless of the
presence of a 6mA DC detector, this can be installed without any problems.
14
Mini SIM card
APN username and password
TLS 1.2 x509 2048/4096 bit root certificate
HTTP Basic authentication, with or without TLS
Not supported
Encryption: AES 128 bit
Encrypted and digitally signed
Encryption: SHA256 hash (pkcs1/PSS padding with 2048 RSA key)
Signature: RSA public key 2048 bit
AES 128 bit (erased when read)
Installed in the factory, update through UpdateFirmwire file
1
Fixed cable
Type 2 socket, in accordance with IE62196-2
TN-C, TN-C-S, TT, IT grid
400VAC (3x230VAC)
32A per phase
22kW
Cable gland, clamping range for 14-25.5mm cable thickness
Cable clamps on input filter block. Range:
• 10mm per vein: solid (VD) wire
2
• Max. 6mm per vein: stranded (VDS) wire with ferrules
2
Integrated, simultaneous activation
Extra safety relay in series
Integrated 6mA DC leakage current detection
Response time: 1-5 seconds
Integrated in firmware; shut down at: 105% after 1,000 seconds;
110% after 100 seconds; 120% after 10 seconds; 150% after 2 seconds.
RJ45 (Ethernet/LAN)
RJ11 (active load balancing)
