REMARK
The Service Installer application is available for download
for Microsoft Windows on: www.alfen.com/en/downloads.
See the chapter 'EV charging points' . If you do not yet have
an account to use the Service Installer application, you can
request one through http://support.alfen.com ->
'Configuration Tool' -> 'Sign up for an account' .

4.1 Safety instructions before use

Follow the safety instructions below before commissioning
your charging station:
1. Make sure the charging station is properly connected
to the power supply as described in this manual.
2. Make sure the distribution of the power supply is
separately protected by an appropriate breaker
(MCB or fuses)
3. Make sure the charging station is installed in
accordance with this manual.
4. Make sure the casing is always closed during
normal operation.
5. Make sure the charging cable is not twisted and that
the cable, plug and casing do not have any damage.

4.2 Commissioning Eve Single Pro-line DE models

Turn on the local power supply. The charging station will
run self diagnostics. The following steps will occur within
a few seconds:
1. The output is tested:
- Testing locks
- Testing internal relays: you will hear these click.
2. The display will illuminate briefly.
3. The display turns on and displays the message
'Charging station is powering up' .
4. The display will show the start screen, recognisable
by the logo on the screen.
5. The Eve Single Pro-line DE is now ready for use. If
the charging station is set to connect with the
management system, it will do so directly and
automatically.
6. If desired, the charging station can be configured
further. Use the Service Installer software package
to gain access.
7. Have you had the charging station configured for
Smart Charge functionality? If so, check the settings
with the Service Installer application to optimally
configure the charging station for the local situation.
More information is available in Appendix B.
Eve Single Pro-line DE manual | Version 1.0 | February 2020

4. COMMISSIONING THE CHARGING STATION

4.3 Configuring the charging station with Service
Installer Application

4.3.1 Preparation

Eve Single Pro-line DE charging stations are easily
configured using the Service Installer Application. This
application allows you to access many settings, view the
factory settings and see all the completed transactions and
recognised charge passes.
The version number of the Service Installer Application is
connected with that of the firmware to show you which
new functionalities are supported by your charging station.
Tip: Before installing the charging station, make sure you
have a user account and are using the newest version
of the Service Installer Application. You can request an
account at: http://support.alfen.com. Click on 'Sign up for an
account' . Note that new account creation may take several
working days.
Connect the charging station to your laptop with an
Ethernet cable (UTP).
