2.6.11 External protection according to EV/ZE-Ready

NOTICE!
An installation in accordance with the EV/ZE Ready standard requires a high immunity type Residual Current Breaker
(if a type A RCD is applied). The RCD must comply with Level 4 specifications.
IEC 61000-4-16 or IEC 61543
Frequency range
1 kHz - 1.5 kHz
1,5 kHz - 15 kHz
15 kHz - 150 kHz

2.7 Optional factory settings

Description
Authorisation
Maximum charging current
Smart Charge options
(see Appendix B)
Own logo in display
Languages supported
User availability if temporarily
offline
Action if plug is released on vehicle
side
Choice of management system
Communication through *
* Settings may incur additional costs.
The default settings are always displayed first.
Eve Single Pro-line DE manual | Version 1.0 | February 2020
Level 3
Cont. test Vrms (V) Current (mA)
1 6.6
1 - 10 6.6 - 66
10 66
Options
Plug & Charge
RFID*
16A
32A*
Off
Active load balancing*
Smart Charging Network*
Off (Alfen logo)
On (your own logo)
English, Dutch, German, French, Spanish, Portuguese, Italian, Norwegian,
Swedish, Finnish
Accept all RFID passes
Only valid passes in database
Not available
Stop transactions and release the plug
Pause charging until cable plugged back in
Stand alone, ICU Connect*, other options*
GPRS, UTP/LAN, Autodetect
2. PRODUCT
Level 4
Cont. test Vrms (V) Current (mA)
3 20
3 - 30 2 - 200
30 200
