2. PRODUCT

2.6.9 Casing

Type
Mounting options
Material
Colour
Locking
Dimensions Eve Single Pro-line DE Socket (H x W x D)
Casing
Packaging
Dimensions Eve Single Pro-line DE Fixed (H x W x D)
Casing
Packaging
Weight
Casing
Total, incl. packaging

2.6.10 Installation instructions

NOTICE!
Your installation must comply with the standards and regulations of the location (country) where it is installed. The tables
below are recommended and based on the proper practical functioning of the charging stations, provided all necessary
conditions are met.
Printing errors are expressly reserved
Input: minimal
recommended cable
diameters (based on
assumed max. 50m
cable length)
Short-circuit protection
Residual current
protection (possibly
i.c.w. circuit breakers)
Nominal input voltage
Nominal frequency
Grounding
Connection method
16
3-phase 11kW charging, 16A per phase: 5 x 4 mm
3-phase 22kW charging, 32A per phase: 5 x 6 mm
With breaker circuits:
3-phase 16A (11kW): 1 x 20A, 3P, type B or C
3-phase 32A (22kW): 1 x 40A, 3P, type B or C
Earth leakage circuit breakers: 30mA type A or B, 4P
11kW charging: minimum 20A
22kW charging: 40A
For specific EV/ZE Ready requirements, see paragraph 2.6.11 for detailed specifications and
related requirements for the installation
• V : 230VAC (+/-10%)
L1-N
• V : 230VAC (+/-10%)
L2-N
• V : 230VAC (+/-10%)
L3-N
• V : 400VAC (+/-10%)
L1-L2
• V : 400VAC (+/-10%)
L1-L3
• V : 400VAC (+/-10%)
L2-L3
• V : ≈ 0VAC
PE-N
50 Hz
TN system: PE cable
TT system: separately installed grounding electrode < 100 Ohm spreading resistance
IT system: connected to a shared reference (common earth) with other metal parts
Permanently connected
Wall-mounted unit
Wall mounting or mounting post (accessory)
Polycarbonate, UV resistant and flame retardant
RAL9016 (Traffic White): front side
RAL 7043 (Traffic Grey B): rear
Torx T20 screws
370 x 240 x 175mm
470 x 320 x 290mm
470 x 320 x 290mm
470 x 320 x 410mm
Approx. 4,5 kg
Approx. 5 kg
.
2
.
2
With fuses:
3-phase 16A (11kW): 3 x 20A gG
3-phase 32A (22kW): 3 x 35A gG
Eve Single Pro-line DE manual | Version 1.0 | February 2020
