The table below provides an overview of values that can be read. Because the charging stations adjust to the currents per
phase (bold in the table), this is the minimal information necessary to operate the active load balancing.
Measured value
Voltage L1L2 [V]
Voltage L2L3 [V]
Voltage L3L1 [V]
Voltage L1N [V]
Voltage L2N [V]
Voltage L3N [V]
Frequency [Hz]
Current L1 [A]
Current L2 [A]
Current L3 [A]
Current N [A]
Active Power Sum [W]
Reactive Power Sum [VAr]
Apparent Power Sum [VA]
Cos(phi) Sum [ ]
Active Power L1 [W]
Active Power L2 [W]
Active Power L3 [W]
Reactive Power L1 [VAr]
Reactive Power L2 [VAr]
Reactive Power L3 [VAr]
Apparent Power L1 [VA]
Apparent Power L2 [VA]
Apparent Power L3 [VA]
Cos(phi) L1 [ ]
Cos(phi) L2 [ ]
Cos(phi) L3 [ ]
B.2 Smart Charging Network
The Smart Charging Network (SCN) is the smart charging functionality that makes connected Alfen charging stations
form a single charging plaza. For every outlet used, the network decides how fast it can charge, taking the total load into
account. To achieve this, all connected charging stations exchange data on the current charging capacity for all users.
Eve Single Pro-line DE manual | Version 1.0 | February 2020
APPENDIX B: DEFAULT SELECTIONS FOR
OPTIONAL FACTORY SETTINGS
Step size Data type
0.01 [V] UNSIGNED32
0.01 [V] UNSIGNED32
0.01 [V] UNSIGNED32
0.01 [V] UNSIGNED32
0.01 [V] UNSIGNED32
0.01 [V] UNSIGNED32
0.001 [Hz] UNSIGNED32
0.001 [A] UNSIGNED32
0.001 [A] UNSIGNED32
0.001 [A] UNSIGNED32
0.001 [A] UNSIGNED32
0.1 [W] SIGNED32
0.1 [VAr] SIGNED32
0.1 [VA] UNSIGNED32
0.001 [ ] SIGNED32
0.1 [W] SIGNED32
0.1 [W] SIGNED32
0.1 [W] SIGNED32
0.1 [VAr] SIGNED32
0.1 [VAr] SIGNED32
0.1 [VAr] SIGNED32
0.1 [VA] UNSIGNED32
0.1 [VA] UNSIGNED32
0.1 [VA] UNSIGNED32
0.001 [ ] SIGNED32
0.001 [ ] SIGNED32
0.001 [ ] SIGNED32
