2. PRODUCT

2.3 Operation

Specific user actions are presented in a sequence that clearly shows the progress and corresponding status indications.
The first steps can be conducted in any sequence. Upon detecting a charging cable or charge pass, all Eve Single Pro-line DE
products will show the green check mark symbol. The light blue (cyan) hourglass symbol will only be displayed if and when
a connection between the vehicle and charging station is established. During charging the status indicator will show the
charging transaction is active.
Start
Pro-line
Stop
Pro-line
Start
Pro-line
Stop
Pro-line
10
Operation Plug & Charge – Authorisation without a charge pass
1
1
RFID - Charging station with user authorisation
1 2
1 2
2 3
2 3
3
3
Eve Single Pro-line DE manual | Version 1.0 | February 2020
--kW
--kW --.--kWh
--.--h
4
--kW
--kW --.--kWh
--.--h
4
