3 SET-UP
3.6

INITIAL INSPECTION_______________________________________________________

The initial inspection should be performed only when the engine is off and all fluids are cold. Lower decks to the
ground, engage parking brake, stop engine, and remove ignition key.
1. Perform a visual inspection of the entire unit, look for
signs of wear, loose hardware, and components that
may have been damaged during transport.
2. Inspect paint and decals for damage or scratches.
Decals provide important operating and safety
information. Replace all missing or hard to read
decals.
3. All fluids must be at the full level mark with engine
cold.
Check:
a. Radiator coolant level.
b. Engine oil level.
3.7

OPERATING CHECKS______________________________________________________

After the initial inspection test the mower for proper
operation. If mower is being fitted an accessory you may
want to assemble these and check operation of the
mower with accessory attached.
1. Test the Interlock System.
[Section 3.8]
2. Start mower and check that switches, pedals and
controls operate as described.
[Section 2.2]
3. Check that warning lights and alarm are working.
4. Check that brake pedal does not have more than
one inch free travel before engaging.
5. Operate traction pedal and check that mower
operates smoothly in both directions. Check that
mower stops when traction pedal is released.
6. Check that mower does not drift with engine running
and traction pedal in Neutral.
[Section 4.7 and 4.11]
7. Check adjustment of traction pedal speed limiter.
[Section 3.9]
8. Check that decks raise and lower correctly and that
power take-off switch operates. Make sure blades
turn off when decks are raised. [Section 4.10]
9. After operation, stop mower and inspect again for oil
or hydraulic leaks.
13
!
CAUTION
c. Hydraulic fluid level.
4. Make sure air filter connections are tight and cover
is securely in place.
5. Check tires for proper inflation. Tires have been
over inflated for transport. Check engine belt
tension.
6. Inspect battery connections and electrolyte level.
Check that battery is fully charged.
7. Check for fuel or oil leaks.
8. Inspect lube points on mower for proper lubrication.
10. Check and if necessary adjust cutting height and
level decks. [Sections 4.2, 4.4, and 4.5]
