Instructions Electronic Add-On Voice / Display / Real Time Clock
GB
GB
Configurations and Set-up
Code
Parameter
Timer control code lock button:
46
0 = disabled
1 = code lock function enabled according to schedule no. 1
2 = code lock function enabled according to schedule no. 2
3 = Relay 1 activated according to schedule no. 1 or else code lock func-
tion
4 = Relay 1 activated according to schedule no. 2 or else code lock func-
tion
5 = Relay 2 activated according to schedule no. 1 or else code lock func-
tion
6 = Relay 2 activated according to schedule no. 2 or else code lock
function
Once you enable timer control for the code lock function (provided it has
been enabled via configuration step 16), using the code lock function is
limited to the validity periods set by the schedules. When set to opera-
tions modes 3 and 4 or 5 and 6 respectively, your pressing the code lock
button during validity periods will result in Relay 1 or Relay 2 activation
for the determined activation interval. However, this only works for relay
operations modes 1 to 6. Outside the set validity periods, pressing the
code lock button will activate the code lock function, provided it has
been enabled via configuration step 16.
Timer control speed dial button:
47
0 = disabled
1 = speed dial function enabled according to schedule no. 1
2 = speed dial function enabled according to schedule no. 2
Once you enable timer control for the speed dial function (provided it has
been enabled via configuration step 16), using the speed dial function is
limited to the validity periods set by the schedules.
Timer control direct call:
48
Schedule [beep] direct call button [beep]
Enable this option to automatically place a direct call according to a set
schedule as if the corresponding direct call button had been pressed. To
do so, this configuration step wants you to enter the schedule's number
(1 for schedule no. 1 or 2 for schedule no. 2) and the direct call button's
telephone number (1 for button no. 1, ...., 8 for button no. 8, 9 for the
number keypad's i key) to be automatically dialled according the times
set in the schedule. The selected schedule defines the times at which a
direct call is placed. Please note that the direct call will be placed once
the beginning of a valid schedule is reached. In case you also wish for the
direct call to be placed at the end of a valid schedule, add the * symbol
after setting the schedule no.
Please note: To use the "timer control direct call" function you need an
additional power supply 12 V
50
Confirmation
default: 0
#
#
#
#
#
#
#
default: 0
#
#
#
default: 0
#
