Instructions Electronic Add-On Voice / Display / Real Time Clock
GB
GB
Configurations and Set-up
Code
Parameter
Schedule 1:
41
Day of the week [beep] schedule
To use time-controlled functions, you need to set a schedule in order to
define the respective times. To do so, you may set up to three time peri-
ods (beginning and end) for each day of the week. At first, this configu-
ration step wants you to enter the day of the week to which the following
schedule should apply. The day of the week (=D) is entered with a single
digit from 1 to 7.
Mon=1, Tue=2, Wed=3, Thu=4, Fri=5, Sat=6 and Sun=7
After having entered a valid day of the week you will hear a beep con-
firming your entry. Then you may enter the schedule for the day of the
week in question. To do so, enter the desired times as hours (=HH) and
minutes (=MM) using the format HHMM, e.g. 0815 for 8.15 am. A schedule
is set for periods of time and you need to define beginning and end. For
each day of the week, you may set up to three periods of time. You need
to enter the separate periods of time in their correct chronological order
and these periods may not overlap. Use the following structure to enter a
schedule for any given day of the week D (D=1-7):
D [beep] HHMM HHMM [beep] HHMM HHMM [beep] HHMM HHMM [beep]
# Day
Example:
Validity period: Mondays from 8:00 am to 4:30 pm.
1 [beep] 0800 1630 [beep] #
Example:
Validity period: Wednesdays, 8:00 am to 12:00 pm and 3:30 pm to 6:05
pm
3 [beep] 0800 1200 [beep] 1530 1805 [beep] #
Example:
Validity period: Fridays, enter no times to delete a previously set sche-
dule
5 [beep] #
Please note: Making invalid entries like an invalid time code (e.g. 2930)
or setting an incomplete schedule (e.g. 0800 160) or when a schedule
overlaps (e.g. 0800 1200 10), the device will produce an error tone and
the schedule for the corresponding day of the week will be deleted.
48
period 1
period 2
Confirmation
Parameters: cf. text
#
period 3
