Building package MSH Basic-FUBO-GK-SR4 / MBK-R4

10 Required tool and auxiliaries

For proper installation of the multiple-service building entry MSH Basic-FUBO-GK-SR4/
MSH Basic-MBK-R4, the usual standard tools are required.
In addition:
– Torque wrench 1/4"+ Internal hex socket wrench 6 mm
(e.g. Hauff MSH/GEH tool set)
– GMT lubricant (Art. No. 2790009100)
11 The following instructions are to be observed prior to installation of the
building package MSH Basic-FUBO-GK-SR4/MSH Basic-MBK-R4:
WARNING!
Risk of injury in the event of improper installation!
Improper installation can result in significant bodily harm and property damage.
• Incorrect cable/duct installation and improper filling of the cable trench results
• When installing the building package MSH Basic-FUBO-GK-SR4/MSH Ba-
• The nationally applicable laying and filling regulations for pipes and cables are
• Seal the surface and pipe substructure well prior to laying pipes/cables so that
• The relevant country specific standards and regulations are to be observed when
• For details of other accessories and further information, see www.hauff-technik.de

12 Preparing for installation

1
For precise positioning of the MSH Basic-FUBO-GK-SR4
(basic unit), a batter board must be prepared on site.
The line ideally identifies both the upper edge of the
unfinished floor, as well as the wall inner side (see fig.:1)
26
in subsidence and can therefore potentially cause damage and leaks.
sic-MBK-R4, it is imperative to observe the relevant professional association
rules, the VDE provisions, the relevant national safety and accident prevention
regulations and your company's guidelines (work and procedure instructions).
to be observed at all times.
the latter cannot subside.
carrying out concreting work. This applies especially to concrete construction
elements according to EN206-1 which are impermeable to water.
and the technical specification sheets.
Art. Nr.: 5090032089 Rev.: 01/2018-07-05
EN
Fig.: 1
