5 Electrical installation
Wiring
EMC−compliant wiring
EMC−compliant wiring
(Design of a CE−typical drive system)
)
Note!
Control cables and mains cables must be separated from the motor cable to avoid
ƒ
interference injections.
Always use shielded control cables.
ƒ
Generally we recommend to shield the cable for the PTC or thermal contact and
ƒ
route it separately from the motor cable.
If you route the cores for the motor connection and the cores for the connection of
ƒ
the PTC or thermal contact within one cable with a common shield:
To reduce interference injections on the PTC cable we recommend to additionally
–
install the PTC kit type E82ZPEx.
Optimum HF shield connection of the motor cable is obtained by using the terminal
ƒ
2for motor PE and motor shield.
