Wiring; Mains Choke/Mains Filter Assignment - Lenze Global Drive8200 vector Montageanleitung

5 Electrical installation

Wiring

Mains choke/mains filter assignment

Wiring
Mains choke/mains filter assignment
Operation at rated power on 230 V mains, 1/N/PE
8200 vector
Type Var.
E82xV251K2C 0xx
2xx
E82xV371K2C
0xx
2xx
E82xV551K2C 0xx
2xx
E82xV751K2C
0xx
2xx
E82xV152K2C 0xx
2xx
E82xV222K2C 0xx
2xx
1)
The motor cable length depends on the inverter type and the switching frequency
114
Mains choke Interference voltage category (EN 61800−3) and motor cable
Type
ELN1−0900H005
E82ZZ37112B220
E82ZZ37112B200
E82ZZ37112B210
ELN1−0900H005
E82ZZ37112B220
E82ZZ37112B200
E82ZZ37112B210
ELN1−0500H009
E82ZZ75112B220
E82ZZ75112B200
E82ZZ75112B210
ELN1−0500H009
E82ZZ75112B200
E82ZZ75112B210
ELN1−0250H018
E82ZZ22212B200
E82ZZ22212B210
ELN1−0250H018
E82ZZ22212B200
E82ZZ22212B210
l
length
Component
C2 Max.
[m]
− 20
5 E82ZZ37112B220
20 E82ZZ37112B200
50 E82ZZ37112B210
− 20
5 E82ZZ37112B220
20 E82ZZ37112B200
50 E82ZZ37112B210
− 20
5 E82ZZ75112B220
20 E82ZZ75112B200
50 E82ZZ75112B210
− 20
20 E82ZZ75112B200
50 E82ZZ75112B210
− 20
20 E82ZZ22212B200
50 E82ZZ22212B210
− 20
20 E82ZZ22212B200
50 E82ZZ22212B210
Component
C1 Max.
[m]
1)
−
5
20
50
1)
−
5
20
50
1)
−
5
20
50
1)
−
20
50
1)
−
20
50
1)
−
20
50
EDK82EV222 DE/EN/FR 13.0
