Operation with rated power at the 230V mains, 3/PE
8200 vector
Type Var.
E82xV551K2C 0xx
2xx
E82xV751K2C
0xx
2xx
E82xV152K2C 0xx
2xx
E82xV222K2C 0xx
2xx
1)
The motor cable length depends on the inverter type and the switching frequency
EDK82EV222 DE/EN/FR 13.0
Mains choke Interference voltage category (EN 61800−3) and motor cable
Type
EZAELN3004B742
E82ZZ75132B200
E82ZZ75132B210
EZAELN3004B742
E82ZZ75132B200
E82ZZ75132B210
EZAELN3008B372
E82ZZ22232B200
E82ZZ22232B210
EZAELN3010B292
E82ZZ22232B200
E82ZZ22232B210
l
Electrical installation
Mains choke/mains filter assignment
length
Component
C2 Max.
[m]
− 20
20
50
− 20
20
50
− 20
20
50
− 20
20
50
Wiring
Component
C1 Max.
[m]
1)
−
E82ZZ75132B200 20
E82ZZ75132B210 50
1)
−
E82ZZ75132B200 20
E82ZZ75132B210 50
1)
−
E82ZZ22232B200 20
E82ZZ22232B210 50
1)
−
E82ZZ22232B200 20
E82ZZ22232B210 50
