4 Mechanical installation
Mounting with thermal separation (push−through technique)
8200 vector 1.5 ... 2.2 kW
1 Frame
2 Screw M4x10
3 Seal
4 Hexagon nut M4
5 Rear panel of the control cabinet
8200 vector
E82DV152K2C
E82DV222K2C
79.4
E82DV152K4C
E82DV222k4C
1)
If the function module is attached: observe mounting clearance and cable bending radius. The terminals of
function modules in PT design protrude above the housing by 14 mm.
108
a b b
2
244.5 240
Dimensions [mm]
c c d
1 2 1
4.2 71 5
l
1)
d d e
2 3
80 74.5 140
EDK82EV222 DE/EN/FR 13.0
8200vecxxx
1)
f g
100 4.5
