REMOVING THE FRONT WHEEL

Set a stand or a block under the engine and see that
the front wheel is lifted from the ground.
Remove the two screws (1) and the brake calliper (2).
Loosen the bolts (2) holding the wheel axle (3) to the
front fork mounts. Hold the head of the wheel axle
in place, and unscrew the bolt (4) on the opposite
side; draw the wheel axle out.
EN - 48
Note*: Do not operate the front brake lever when
the wheel has been removed; this causes the calliper
pistons to move outwards. After removal, lay down
the wheel with brake disc on top.
2
3
1
2
2
4
