Controls and parts, Fig 1–3
1 Handle
2 Riving knife
3 Splitting column
4 Clamp
5 Hydraulic pump
6 Control arm
7 Protection
8 Holder for table (front)
9 Holder for table (side)
10 Locking hooks
11 Splitting table
12 Ventilation cap
13 Base frame
14 Wheels
15 Ignition switch
16 Stroke adjustment bar
17 Engine
18 Guard
19 Spark plug connector
HL1100GE
Scope of delivery
Control arms with hand guard
Technical data
Dimensions D/W/H
Table height mm
Working height mm
Log length cm
Power max. t*
Piston stroke cm
Forward speed cm/s
Return speed cm/s
Hydraulic Oil quantity
litres
Weight kg
Drive
Engine PS/kW
cylinder capacity ccm
Max. Speed 1/min
Motor Starter
Unleaded gasoline octane number from 90
Fuel
to a maximum ethanol content of 5%
Fuel capacitiy litres
Motor Oil SAE 10W­30 or SAE 10W­40 / 0,6 l
Noise L dB(A)
WA
Technical changes subject to change!
* The maximum achievable splitting power depends on the resist­
ance of the material to be split and can, due to influencing vari­
able, deflect to the hydraulic system.
Hydraulic log splitter
Accessory pack
Wheel Axle
Operating instructions
1020x530x1070/1530
75/380/630/820
930
60/78/103/135
11,0
51
3,2
11
7,0
142,0
4­stroke engine ­ 5.44 / 4
196
2500
Recoil Starter (Pull Starter)
3
106
7
