2. Detailed description of fireplace inserts

2.1. K fireplace inserts (folding wing appliances)
77
Instruction manual
flue gas outlet
(made of cast)
exhaust manifold dome
(made of cast)
exhaust manifold with inte-
grated deflector plate
furnace metal sheet cover-
ing
air-wash air channel
(pane washing)
fireclay furnace
door lock
fire floor front stone
fireclay insert stone
(interchangeable with cast grating
and ash pan accessory)
door
(for lateral opening)
combustion air control
handle
combustion air connection
piece
passage opening
(for outside/fresh air duct)
mount
height adjustable with sound ab-
sorber insert
