Anwendungseinrichtungsbeisp...
FC
+24 V
12
+24 V
13
D IN
18
D IN
19
COM
20
D IN
27
D IN
29
D IN
32
D IN
33
D IN
37
+10 V
50
A IN
53
A IN
54
COM
55
A OUT
42
COM
6
6
39
Tabelle 6.13 Fire Mode
54
Produkthandbuch für VLT
Parameters
Function
Setting
5-11 Klemme 19
[37] Fire
mode
Digitaleingang
24-00 Notfallbet-
[0] Disabled*
riebsfunktion
24-01 Notfallbet-
[0] Open
riebskonfiguratio
Loop*
n
24-02 Einheit
[3] Hz*
Notfallbetrieb
24-03 Fire Mode
0Hz*
Min Reference
24-04 Fire Mode
50Hz*
Max Reference
24-05 Notfall-
0%*
betrieb-
Festsollwert
24-06 Notfall-
[0] No
betrieb-
function*
Sollwertquelle
24-07 Istwert-
[0] No
quelle
function*
Notfallbetrieb
24-09 Alarmhand
[1] Trip,
habung Notfall-
Critical
betrieb
Alarms*
* = Default Value
Notes/comments:
Parameters to setup Fire Mode
are all in the 24-0* group.
®
MG.11.AE.03 - VLT
ist eine eingetragene Marke von Danfoss.
®
HVAC Drive
