FIRST INSTALLATION

The car seat consists of a booster seat (1) and a backrest (2).
The backrest integrates a combined height-adjustment of the
headrest and width-adjustment of the shoulder parts. Only the
combination of these two parts provides best protection and
comfort to your child.
NOTE! Please keep the instruction manual close by for future
!
reference by storing it in the pocket (3) in the front of the seat.
WARNING! Make sure to read, understand and follow
!
the instruction manual.
WARNING! The parts of the CYBEX Solution Z-fix
must not be used alone or in combination with boosters,
backrests or headrests from other manufacturers or
from different product series. In such instances, the
certification expires immediately. Misapplication can
lead to serious injury or death of your child. Please keep
these instructions for future reference.
Connect the backrest (2) to the booster (1) by hooking the
guide lug (4) on the axis (5) of the booster (1).
Insert the "Linear Side-impact Protection" pads (L.S.P.) on
both sides of the shoulder rest into the appropriate installation
holes (6). Push the pads slightly downwards until you hear
!
them, "click" in.
WARNING! Always ensure that the individual
components of the child seat are never compressed
or jammed (e.g. by jamming in the car door or when
adjusting the back seat).
