Insulation saw ISP 330 EB
- Original instruction
Table of contents
1 Technical data .................................... 19
2 Symbols ............................................ 19
3 Operating elements ............................. 20
4 Applications ....................................... 20
4.1 Description ........................................ 20
4.2 Tool properties ................................... 20
5 Safety instructions .............................. 21
5.1 General safety instructions ................... 21
5.2 Insulation saw ISP 330 EB
- safety information ............................ 21
5.3 Residual safety risks ............................ 23
5.4 Emission levels ................................... 24
6 Transport and delivery ......................... 24
6.1 Storage ............................................. 24
7 Adjustment ........................................ 24
7.1 Tilting the guide bar lengthwise ............ 24
7.2 Cutting angle adjustment ..................... 24
7.3 Motor electronics ................................ 24
8 Preparation for use.............................. 25
8.1 Mounting the chain ............................. 25
8.2 Filling the oil reservoir ......................... 25
8.3 Electrical connection ............................ 25
9 Operation .......................................... 25
9.1 Switching on and off ............................ 25
9.2 Controlling chain and guide bar
lubrication ......................................... 26
9.3 Cut indicator ...................................... 26
9.4 Guide ruler......................................... 26
9.5 Exhaust ............................................. 26
10 Using accessories ................................ 26
10.1 The PROTOOL guide system ................. 26
10.2 Assembling the guide rail
(GRP 800/1400/3000-2) ...................... 26
10.3 Assembling the angle guide
(GRP-AG-2) ........................................ 26
10.4 Assembling the connector (CN-GRP) ...... 26
10.5 Assembling the quick clamp
(GRP-Rapid/L) .................................... 26
11 Care and maintenance ......................... 27
11.1 Chain tension ..................................... 27
11.2 Maintaining and sharpening the chain .... 27
11.3 Lubricating the chain ........................... 27
11.4 Maintaining the guide bar ..................... 27
11.5 Maintaining the chain sprocket .............. 27
11.6 Replacing the chain and guide bar ......... 27
11.7 Replacing the chain sprocket ................ 28
11.8 Lubrication and cleaning ...................... 28
11.9 Replacing the carbon brushes ............... 28
12 Environmental Protection / Disposal ........ 28
13 Warranty ........................................... 28
14 Declaration of Conformity .................... 29
15 Service .............................................. 29
15.1 Troubleshooting .................................. 29
GB
1

Technical data

System voltage
Network frequency
Rated input
Movable supply
Circuit breaker
Pre-selection of number of rotations
Constant electronics
Electric safety brake
Restricted circuit power
Speed of sprocket wheel
at the electronics set
at the level of:
Maximum chain speed
Mutual inclination
of the guide reglet
Weight (tool included)
Depth of the cut
[Guide reglet 13" (33 cm)]
at 0°
at 15°
at 30°
at 45°
at 60°
Protection class
Automatic lubrication
of the guide reglet
Oil tank volume
2

Symbols

Double insulation
Warning of general danger
Risk of electric shock
Use protective goggles!
Wear ear protection!
Wear a dust mask!
Use protective gloves!
Do not expose to rain!
Unplug the cord immediately if it is cut or
damaged
Read the instructions
Not for use on wood!
Acoustic output value
Not to be included in municipal refuse
Advice or tip
►
230 V ~
50 / 60 Hz
1600 W
H07RN-F
15 - 16 A
current protection
•
•
•
•
2200 - 4600 min
-1
12 m/s
0° - 60°
7 kg
330 mm
315 mm
285 mm
230 mm
165 mm
II /
•
~ 240 ml
19
