14 Declaration of Conformity

Insulation saw
ISP 330 EB
We declare under our sole responsibility that this
product is in conformity with the following stand-
ards or standardization documents:
EN 50 366, EN 55 014-1, EN 55 014-2, EN 60 745-1,
EN 60 745-2-13, EN 61 000-3-2, EN 61 000-3-3
according to the provision of the regulations stip-
ulated in Directive 2006/42/EC, 2004/108/EC,
2000/14/EC.
All the procedures were applied as validly amended
at the time of the issue of this declaration, without
quoting these.
Technical documentation is kept at the manufac-
turer.

15 Service

Any repairs during and after the warranty period shall be performed by the service centres listed.

15.1 Troubleshooting

Problem
The machine will not run
The cut is not clean; the chain
goes to the side
Strong force required to move
the machine into the cut
The chain is not lubricated
Serial no.
765700
Cause
No power supply
Worn brushes
Stuck switch
When overloaded
Moves into cut too far
Blunt tool
The chain is not sharpened properly Replace the chain with a new one
The supporting area of the runner
is dirty
Blunt tool
Moves into cut too far
Blocked lubrication grooves on the
guide bar
Defective oil feed pump
Empty oil reservoir
The machine's inner oil channels
are clogged or the bio oil has
solidifi ed
11
Stanislav Jakeš
Research and development
Protool GmbH
Wertstr. 20
D-73240 Wendlingen
31. 1. 2011
Solution
Check the safety fuses and the
power cords
Replace the brushes
Press the unblocking button
Check the safety fuses
Reduce the movement
Sharpen the chain or replace it
with a new one
Clean it
Sharpen the chain or replace it
with a new one
Reduce the movement
Clean the guide bar
Replace the pump
(at an authorised service centre)
Replenish chain oil
Clean the machine
(at an authorised service centre)
29
