Technical data

Type reference
Voltage
Lateral guide
Mortising depth
Grooving depth
Rated input
Output
Drive sprocket speed
Weight of the electric tool
Protection class
* with the guide frame GMP 145 only

Included in the delivery:

1 Complete chain cutting tool,
1 Lateral guide,
1 Spanner 19 DIN 894,
1 Double-sided spanner 10/13 DIN 895,
1 Hexagon key 6 DIN 911,
1 Operating Manual,
1 List of service workshops
Operating controls & Description
1. Mains switch actuator
2. Lock-off button
3. Hand screw
4. Safety guard
5. Hexagon nut
6. Locking nut
7. Chain tensioning screw
8. Roller bearing
9. Stauffer lubricator
10. Depth gauge
11. Locking lever for depth gauge adjustment
12. Lateral guide
13. Locking lever for lateral guide adjustment
14. Tubular spirit level
15. Splinter guard fixing screw
16. Splinter guard
17. Sight window
18. Brush cap
19. Carbon brushes
The accessories shown or described in this Operating Manual
may not be included as a part of delivery.
GB
CMP 150
~
230 V
0 - 150 mm
0 - 100 mm / 0 - 150 mm*
0 - 400 mm
2 000 W
1 400 W
4 250 min -1
8,5 kg
II /

Intended use

The chain mortiser is designed exclusively for mortising
and cutting grooves in solid wood.
Any other usage is to be considered not within the inten-
ded range of application. The manufacturer is not liable
for damages resulting from such usage and the user is the
only one to be held responsible for the risks involved.
Observation of the conditions for operation, maintenance
and servicing prescribed by the manufacturer makes part
of the intended range of application.
The chain mortiser may only be used, maintained and
serviced by such persons who are competent for this,
who are familiar with the electric tool and have been
informed about all the dangers concerned.
For free-hand mortising, use only chain cutting tools
designed for maximum mortising depth of 100 mm.
The range of applications and operation modes may
be extended by using the accessories listed in this
Operating Manual.
The user is solely liable for damage and accidents caused
by improper use of the product.
For safe work with this electric tool and prevention of injury,
it is imperative to follow all generally accepted safety
principles and regulations for prevention of accidents,
and read the enclosed „Safety instructions" thoroughly.
The manufacturer disclaims liability for damages caused
by unauthorized modifications or using other than the
supplied or specified accessories with the electric tool.

Safety instructions

This electric tool may only be used, maintained and repaired
by the people who have received the relevant instructions.
These people must have reached the minimum age legally
required. For safe work and familiarizing with all the
remaining risks, they must have read and understood
this Operating Manual.
