b) Adjusting the Tooth Profile Clearance

If the electric motor, the motor pinion or the main drive gear is exchanged, the tooth profile clearance must be adjusted.
To do so, loosen the two attachment screws until the motor can be moved easily by hand (the motor should not waggle
in its mountings!). The motor pinion and the main drive gear now engage without clearance.
Now take a narrow paper strip (thin letter paper) and place it on the top between the cogs.
Now move the main drive gear by hand so that the paper strip is drawn in to sit between the two cogs.
The paper positioned between the cogs lifts the electric motor as far as is necessary to ensure the correct clearance.
Now tighten the screws to fasten the motor in the correct position.
When you turn back the main drive gear afterwards so that the paper strip can be taken out again, the correct clearance
will be set between the cogs.
If the pinion is positioned too close to the main drive gear, the drive works too tightly and the drive power
is reduced.
If the pinion is too far from the main drive gear, the cog teeth can slip which leads to instant irreparable
damage to the main gear.
c) Changing the Crystal
There is not allowed to be any other transmitter/models with the same frequency in the range of the transmitter, as the
transmitters will interfere with each other. As a result, the models no longer respond correctly to the transmitter commands.
If there are other model vehicles in your range, talk to the other operators about the frequencies they use.
Only use suitable accessory crystals for the transmitter and the receiver.
Prior to a quartz change, first turn off the vehicle and then the transmitter.
