IMPAC pyrometer IP 140-LO
Caution: The radiation temperature in the spot area of the pyrometer is not allowed to be
higher than 150°C above the end of the basic range because the temperature sen-
sor can be damaged.
2.1

Appropriate use

The IP 140-LO is a digital, highly accurate pyrometer with fiber optics for non-contact measurement of low
temperature on metals, ceramics, graphite etc. from 100°C.
The transmission between optical head and converter is done via 0.6 mm mono fiber with a stainless steel
protection hose. The optical head contains only the lens, the sensor and the electronics are located in the
converter. Fiber and optical head can be used in ambient temperatures up to 200°C without additional cool-
ing (fiber at converter side max. 125°C). The length of the fiber depends on the temperature ranges (see
technical data).
2.2

Scope of delivery

Converter, fiber, one selectable optical head, works certificate, InfraWin operating and analyzing software,
user manual.
Note: A connection cable is not included with the instrument and has to be ordered
separately (see section 15, Reference numbers).
3

Safety

This section offers an overview about important safety aspects.
Additionally in the several sections there are concrete safety aspects to avert danger. These aspects are
indicated with symbols. Labels and markings at the instrument have to be noticed and keep in a permanent
readable condition.
3.1

General

Each person working with the pyrometer must have read and understood the user manual before operation.
Also this has to be done if the person already used similar instruments or was already trained by the manu-
facturer.
The pyrometer has only to be used for the purpose described in the manual. It is recommended to use only
accessories offered by the manufacturer.
3.2

Laser targeting light

For easy alignment to the measuring object the pyrometers can be equipped with a laser targeting light. This
is a visible red light with a wavelength between 630 and 680 nm and a maximum power of 1 mW. The laser
is classified as product of laser class II.
Warning: To reduce the risk of injury to the eyes, do not look directly into the
targeting laser and do not point the targeting laser into anyone's eyes.
The instrument is equipped with a class II laser that emits radiation.
Safety regulations:
•
Never look directly into the laser beam. The beam and spot can be watched safely from side.
•
Make sure that the beam will not be reflected into eyes of people by mirrors or shiny surfaces.
3.3

Electrical connection

Follow common safety regulations for mains voltage (230 or 115 V AC) connecting additional devices operat-
ing with this mains voltage (e.g. transformers). Touching mains voltage can be mortal. A non expert connec-
tion and mounting can cause serious health or material damages.
Only qualified specialists are allowed to connect such devices to the mains voltage.
