IMPAC pyrometer IP 140-LO
5.2.2

Serial number

The original fiber has a serial number which is also on the
pyrometer's housing.
If required the fiber can be replaced by a new original
IMPAC fiber. In this case the pyrometer has to be calibrated
together with the fiber (service).
5.3

Minimum bending radius

For short time: 150 mm
Permanent: 500 mm
Note: A hot fiber optic cable should not be exposed to continual movement!
5.4

Optical head

The FSMA connector on the side of the optical head
doesn't need a special justification if bold together with
the screw connection.
The optical heads can be changed against each other
from the same type. A recalibration of the pyrometer is
not necessary
5.5

Accessories (optional)

Numerous accessories guarantee easy installation of the pyrometer. The following overview shows a selec-
tion of suitable accessories. You can find the entire accessory program with all reference numbers on sec-
tion 15, Reference numbers.
Mounting:
For mounting and aligning the optical head to the meas-
ured object mounting angles or a ball and socket mount-
ing is available. The ball and socket mounting is an easy
way to align the pyrometer to the measured object. The
clamping-screws of the ball and socket mounting enable
an easy and fast adjustment of the pyrometer in all
directions.
Air purge:
The air purge protects the lens from contamination with
dust and moisture. It has to be supplied with dry and oil-
free pressurized air (1.5 m³ / h) and generates an air
stream shaped like a cone.
Displays:
Additionally to the built-in temperature indicator of the
pyrometer IMPAC offers several digital displays which
can also be used for remote parametrizing of the py-
rometer.
Serial number
FSMA connector with
screw connection
Mounting angles
Air purge
Digital display
LED large display
DA 6000
Optical head
Ball and socket mounting
11
