IMPAC pyrometer IP 140-LO
15

Reference numbers

15.1

Reference numbers instruments

3 875 910 100 ... 650°C
3 875 930 110 ... 670°C
3 875 920 130 ... 750°C
Ordering note:
When ordering please select one optics (also see section 7, Optical head).
A connection cable is not included in scope of delivery and has to be ordered separately.
15.2

Reference numbers accessories

Exchangeable optical head, type
3 873 320 Measuring distance 120 mm
3 873 340 Measuring distance 260 mm
3 873 350 Measuring distance 700 mm
Exchangeable optical head, type
3 838 210 Measuring distance 88 ... 110 mm
3 838 220 Measuring distance 95 ... 129 mm
3 838 230 Measuring distance 105 ... 161 mm
Exchangeable optical head, type
3 873 420 Measuring distance 87 mm
3 873 440 Measuring distance 200 mm
3 820 340 Connection cable, length 5 m, 90° connector
3 820 530 Connection cable, length 10 m, 90° connector
3 820 540 Connection cable, length 15 m, 90° connector
3 820 830 Connection cable, length 20 m, 90° connector
3 820 840 Connection cable, length 25 m, 90° connector
3 820 550 Connection cable, length 30 m, 90° connector
3 820 330 Connection cable, length 5 m, straight connector
3 820 500 Connection cable, length 10 m, straight connector
3 820 510 Connection cable, length 15 m, straight connector
3 820 810 Connection cable, length 20 m, straight connector
3 820 820 Connection cable, length 25 m, straight connector
3 820 520 Connection cable, length 30 m, straight connector
3 834 280 Mounting angle for converter
Mounting angle for optical head Ι (fixed)
3 834 370
Mounting angle for optical head Ι (adjustable)
3 834 380
Ball and socket mounting for optical head Ι or ΙΙ
3 834 390
Adjustable mounting support for optical head ΙΙ
3 834 230
Air purge for optical head Ι
3 835 170
Air purge for optical head ΙΙ
3 835 180
90° mirror for optical head ΙΙ
3 835 240
Power supply for DIN rail mounting NG DC (100 to 240 V AC ⇒ 24 V DC, 1 A)
3 852 290
Power supply NG AC; 230 V AC ⇒ 24 V AC, 750 mA (not for US sale)
3 852 190
3 852 550 power supply NG 2D, as NG 0D: additionally with 2 limit switches (not for US sale)
3 890 640 LED digital display DA 4000-N
3 890 650 LED digital display DA 4000: with 2 limit switches
3 890 560 LED digital display DA 6000-N: with possibility for pyrometer parameter settings for digital
IMPAC pyrometers; RS232 interface
3 890 520 LED digital display DA 6000; DA 6000-N additional with 2 limit switches and analog input and
output
3 826 500 HT 6000, portable battery driven indicator and instrument for pyrometer parameter setting
3 826 510 PI 6000: PID programmable controller, very fast, for digital IMPAC pyrometers
26
(MB 6.5) with 1 m fiber
(MB 6.7) with 2 m fiber
(MB 7.5) with 5 m fiber
Ι:
ΙΙ:
, focusable:
ΙΙ:
, fixed adjusted:
