Schrauben-Anziehdrehmomente (Promag L)
Beachten Sie folgende Punkte:
• Die aufgeführten Anziehdrehmomente gelten nur für geschmierte Gewinde.
• Die Schrauben sind gleichmäßig über Kreuz anzuziehen.
• Zu fest angezogene Schrauben deformieren die Dichtfläche oder verletzen die Dichtung.
• Die angegebenen Anziehdrehmomente gelten nur für Rohrleitungen, die frei von
Zugspannungen sind.
Anziehdrehmomente Promag L für EN (DIN)
Nennweite
[mm]
Druckstufe [bar]
50
65*
80
100
125
150
200
250
300
* Auslegung gemäß EN 1092-1 (nicht nach DIN 2501)
Anziehdrehmomente Promag L für ANSI
Nennweite
[mm]
[inch]
Druckstufe [lbs]
50
2"
80
3"
100
4"
150
6"
200
8"
250
10"
300
12"
EN (DIN)
Schrauben
PN 10/16
4 × M 16
PN 10/16
8 × M 16
PN 10/16
8 × M 16
PN 10/16
8 × M 16
PN 10/16
8 × M 16
PN 10/16
8 × M 20
PN 10
8 × M 20
PN 10
12 × M 20
PN 10
12 × M 20
ANSI
Schrauben
Class 150
4 × 5/8"
Class 150
4 × 5/8"
Class 150
8 × 5/8"
Class 150
8 × ¾"
Class 150
8 × ¾"
Class 150
12 × 7/8"
Class 150
12 × 7/8"
Promag 10
Max. Anziehdrehmoment
[Nm]
40
22
30
42
55
90
130
90
100
Max. Anziehdrehmoment
[Nm]
[lbf · ft]
40
29
65
48
44
32
90
66
125
92
100
74
115
85
