T A K E R A C I N G T O T H E N E X T L E V E L® Video Instruction: bit.ly/nlrbuild INSTRUCTION MANUAL *ELECTRONICS NOT INCLUDED...
Seite 2
T O T H E N E X T L E V E L® instruction booklet to fully optimize your product. N E X T L E V E L R A C I N G . C O M ASSEMBLY VIDEO bit.ly/nlrbuild @next_level_racing @nextlevelracingOfficial @nextlvlracing Next Level Racing FOLLOW support@nextlevelracing.com...
Seite 3
Please ensure T-Nuts are correctly placed within the extrusion. • Lay out and build the cockpit on a level surface. • The F-GT Elite 160 is a 2 person build. • Do not force parts together. • Avoid cross threading bolts.
Seite 4
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com 4 x M8 40mm BOLTS 2 x SEAT BRACKETS (LEFT AND RIGHT) 2 x PEDAL ADJUSTMENT FINS (LEFT AND RIGHT) 4 x END CAP (40 x 40) 14 x M8 20mm BOLTS 8 x M8 35mm BOLTS 6 x M8 45mm BOLTS 88 x M8 WASHERS 4 x M8 16mm COUNTERSUNK BOLTS...
Seite 5
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com TABLE OF CONTENTS DRIVING POSITIONS F-GT ELITE 160 BUILD PAGES: 12 - 28 DIRECT SHIFTER MOUNT PAGES: 29 - 31 CASTOR WHEEL KIT INSTALL PAGE: 32 GT POSITION HYBRID POSITION FORMULA POSITION INTERCHANGEABLE FRONT PANEL how to install END CAPS...
Seite 6
SHOULDER BOLTS The F-GT Elite 160 is fully adjustable from almost every attachment point making it great for all sized users whether that be in GT, HOW TO: Turn the Shoulder Bolt until the thread is protruding Formula or Hybrid position.
Seite 7
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com Note: For easier installation hand Note: For easier installation hand screw M8 Bolt in to T-Nut to assist screw M8 Bolt in to T-Nut to assist T-NUT PLACEMENT sliding T-Nut in to channel. T-NUT PLACEMENT sliding T-Nut in to channel. Note: Slide 2 x Note: Slide 4 x T-Nuts Optional: Slide extra...
Seite 8
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: Note: Height of the foot can be adjusted only when it’s installed on to the cockpit. • • 1 x Front Panel • • 4 x Adjustable Feet (REAR) • • 4 x M8 40mm Bolts •...
Seite 9
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: • • 8 x M8 20mm Bolts • • NIL • • 8 x M8 Washers Loosen the Bolts securing the Wheel Plate to the Left and Right Upright. Adjust to desired position and tighten Align the Left and Right Vertical Post assemblies with the T-Nuts previously installed in Step 01 and the Bolts to lock in place.
Seite 10
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: • • 2 x Pedal Brackets • • 2 x Pedal Adjustment Fins • • 4 x M8 16mm Bolts • • 4 x M8 Washers Align the Pedal Bracket mounting holes with the T-Nuts previously installed in Step 13. Bolt through Align the slots and mounting hole on the Pedal Adjustment Fins with the T-Nuts previously installed in and secure with 4 x M8 Bolts and Washers.
Seite 11
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: Note: Do not tighten the • • NIL • • 8 x M8 16mm Bolts Pedal Plate until you have your desired position. • • 8 x M8 Washers Align the mounting holes on the Seat Slider Tabs with the T-Nuts previously installed in Step 01 and Bolt through and secure with 8 x M8 Bolts and Washers.
Seite 12
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: • • NIL • • 4 x M8 16mm Bolts • • 4 x M8 Washers OVERHANGING Bolt through and secure with 4 x M8 Bolts and Washers. The Seat Brackets are now setup for taller users. PARTS: PARTS: OPTIONAL OVERHANGING SEAT BRACKETS...
Seite 13
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com SHIFTER ARM INSTALLATION PARTS: Note: For Direct Shifter PARTS: Mount, skip to Step 48. (MIRROR STEPS 32 TO 40 FOR RIGHT SIDE INSTALL) • • 1 x Shifter Arm • • 1 x Shifter Arm Support SAME ON OTHER SIDE •...
Seite 14
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: SHIFTER ARM ADJUSTMENT (MIRROR FOR RIGHT SIDE SHIFTER) • • NIL • • 1 x Buttkicker Mount (Bolts to Loosen) • • 2 x M8 16mm Bolts • • 2 x M8 Washers Loosen the Bolts securing the Shifter Arm Brackets to the Vertical Post and Shifter Arm Support. Align the mounting holes on the Buttkicker Mount with the T-Nuts previously installed in Step 22.
Seite 15
A) Install 2 x T-Nuts into each outer channel of the Shifter Arm and 1 x T-Nut into each inner channel. Your F-GT Elite 160 is complete. B) Slide T-Nuts to the marked locations and install 2 x End Caps.
Seite 16
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: DIRECT SHIFTER ADJUSTMENT • • 1 x Shifter Arm Support • • NIL • • 2 x End Caps (40 x 80 Angled) • • 2 x Shifter Arm Brackets (Bolts to Loosen) • • 4 x M8 16mm Bolts •...
Seite 17
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: CASTOR WHEEL KIT INSTALL INTERCHANGEABLE FRONT PANEL • • NIL • • NIL Tip: Use Allen key to loosen the Adjustable Feet. Uninstall 4 x Bolts, Washers and Flange Nuts securing the Front Panel to the Left and Right Base Remove 4 x Adjustable Feet from the cockpit.
Seite 18
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: • • NIL BOTTOM MOUNT SEAT INSTALLATION STEPS Remove the Rear Base Member. PARTS: PARTS: • • NIL • • 1 x Rear Base Member • • 6 x M8 45mm Bolts • • 6 x M8 Washers A) Uninstall the Bolts and Washers securing the Seat Brackets to the Seat Sliders.
Seite 19
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: NOTE: Leave the Seat Slider • • NIL • • 4 x M8 16mm Low-Profile Bolts Members aside for future steps. (Included with Bottom Mount Seats) • • 2 x Seat Slider Members (Previously uninstalled in Step 67) Repeat on all corners...
Seite 20
TALLER USER STEPS: 76 - 77 MOUNTING LOCATION @nextlevelracingOfficial OPTIONAL FOR USERS 170cm OR TALLER @nextlvlracing INVERTED STEPS: 78 - 79 MOUNTING LOCATION Next Level Racing FOLLOW OPTIONAL FOR USERS 160cm OR SHORTER NOTE: ONLY TOP ROW CAN BE USED support@nextlevelracing.com...
Seite 21
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: RECOMMENDED V3 MOTION SETUP • • 2 x Motion Brackets • • 6 x M8 20mm Countersunk Bolts MOUNTED VIEW Bolt through and secure with 3 x M8 Countersunk Bolts. Repeat on the other side. Skip to Step 80. Align the countersunk holes on the Motion Brackets with the NLR Motion V3 mounting holes.
Seite 22
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: Repeat • • NIL • • 4 x Ratchet Handles on Other Side A) Uninstall 4 x M8 Bolts and Washers securing the Seat Brackets to the Seat Sliders Members. Align the mounting holes on the Motion Brackets with the T-Nuts installed in Step 82. Bolt through B) Remove the Seat Brackets.
Seite 23
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: TRACTION PLUS PLATFORM INSTALL • • 4 x End Caps (40 x 40) (Requires Elite Motion Adapter Upgrade Kit) Install 4 x End Caps onto both ends of each Seat Slider Member. *SOLD SEPERATELY PARTS: PARTS: •...
Seite 24
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: • • 1 x Rear Base Member • • 1 x Front Traction Base Member • • 4 x T-Nuts • • 4 x M8 45mm Bolts (Included with Elite Motion Kit) Note: For easier installation hand screw M8 Bolt in to T-Nut to assist sliding T-Nut in to channel.
Seite 25
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: MOTION PLUS PLATFORM INSTALL • • NIL (Front setup) Tip: Use Allen key to loosen the Adjustable Feet. Uninstall 4 x Adjustable Feet from the Left and Right Base Members. PARTS: PARTS: • • NIL •...
Seite 26
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com PARTS: PARTS: • • 2 x T-Nuts • • 1 x Rear Base Member • • 2 x T-Nuts (T-NUT POSITIONS) (T-NUT POSITIONS) Install 2 x T-Nuts into the bottom channel of the Rear Base Member and slide to the marked locations. Install 1 x T-Nut into the bottom channel of the Left and Right Base Members.
Seite 27
Video Instruction: bit.ly/nlrbuild support@nextlevelracing.com MOTION PLUS PLATFORM INSTALL PARTS: (Rear setup) • • 1 x Rear Base Member Please complete Steps 59 - 64 before continuing. • • 2 x T-Nuts (T-NUT POSITIONS) Install 2 x T-Nuts into the bottom channel of the Rear Base Member and slide to the marked locations. PARTS: PARTS: •...
Seite 28
Please ensure T-Nuts are correctly placed within the extrusion. • • 1 x Motion Plus Lay out and build the cockpit on a level surface. The F-GT Elite 160 is a 2 person build. • • 2 x Motion Plus Brackets Do not force parts together.
Seite 29
Le F-GT Elite 160 est entièrement réglable à partir de presque tous les points de fixation, ce qui le rend idéal pour les utilisateurs de toutes tailles, que ce soit en position GT, Formula ou Hybrid.
Seite 30
NLR Motion V3. Pièces : 2 supports de mouvement. • Le F-GT Elite 160 est une construction pour 2 personnes. 79 - Se référer à l’image. Boulonnez et fixez avec 3 boulons à tête fraisée M8. Répétez de l’autre côté. Pièces : 6 boulons à tête fraisée M8.
Seite 31
42 - Zie afbeelding. Lijn de gaten op de NLR-gereedschapssethouder uit met de T-moeren die eerder zijn geïnstalleerd in stap 35. Schroef door en zet vast met 2 x M8-bouten en nylon ringen. Plaats inbussleutels, De F-GT Elite 160 is volledig verstelbaar vanaf bijna elk bevestigingspunt, waardoor hij geweldig is voor gebruikers van alle maten, of dat nu in de GT-, Formula- of Hybrid-positie is. Gebruik het meegeleverde ratel en ratelpunten na gebruik in de gereedschapssethouder.
Seite 32
NLR Motion V3 montagegaten. Onderdelen: 2 x bewegingsbeugels. • De F-GT Elite 160 is gebouwd voor 2 personen. 79 - Zie afbeelding. Schroef door en zet vast met 3 x M8 verzonken bouten. Herhaal aan de andere kant. Onderdelen: 6 x M8 Verzonken Bouten.
Seite 33
Regolare all’altezza desiderata e serrare i bulloni per bloccarli in posizione. La F-GT Elite 160 è completamente regolabile da quasi tutti i punti di attacco, rendendola perfetta per utenti di tutte le dimensioni, sia in posizione GT, Formula o Hybrid. Utilizzare il livello fornito insieme ai 39 - Fare riferimento all’immagine.
Seite 34
80 - Fare riferimento all’immagine. A) Disinstallare 4 bulloni e rondelle M8 che fissano le staffe del sedile ai membri dei cursori del sedile. B) Rimuovere le staffe del sedile. • L’F-GT Elite 160 è una build per 2 persone.
Seite 35
39 - Consulte la imagen. Alinee los orificios o ranuras de montaje en la placa de cambio con las tuercas en T instaladas previamente en el paso 35. Piezas: 1 x placa de cambio. El F-GT Elite 160 es totalmente ajustable desde casi todos los puntos de conexión, lo que lo hace ideal para usuarios de todos los tamaños, ya sea en posición GT, Fórmula o Híbrido. Use el nivel provisto junto 40 - Consulte la imagen.
Seite 36
81 - Consulte la imagen. A) Retire las 4 manijas de trinquete que sujetan las lengüetas deslizantes del asiento a los miembros de la base derecha e izquierda. B) Retire los conjuntos del deslizador del asiento. • El F-GT Elite 160 es una construcción para 2 personas.
Seite 37
Stellen Sie die gewünschte Höhe ein und ziehen Sie die Schrauben fest, bis sie einrasten. Der F-GT Elite 160 ist von fast jedem Befestigungspunkt aus vollständig einstellbar und eignet sich daher hervorragend für Benutzer aller Größen, egal ob in GT-, Formula- oder Hybrid-Position. Verwenden Sie die 39 - Siehe Bild.
Seite 38
81 - Siehe Bild. A) Entfernen Sie 4 x Ratschengriffe, mit denen die Sitzschieberlaschen an den rechten und linken Basiselementen befestigt sind. B) Entfernen Sie die Sitzgleiterbaugruppen. • Der F-GT Elite 160 ist ein 2-Personen-Modell. 82 - Siehe Bild. A) Entfernen Sie die Endkappen auf der Rückseite der linken und rechten Basiselemente. B) Installieren Sie 2 x T-Muttern im oberen Kanal der linken und rechten Basiselemente. C) Bringen Sie 2 x •...
Seite 39
40 - 画像を参照してください。 ボルトで固定し、 4 x M8 ボルトとワッシャーで固定します。 パーツ: 4 x M8 16mm ボルト、 4 x M8 ワッシャー。 F-GT Elite 160 は、 ほぼすべてのアタッチメント ポイントから完全に調整できるため、 GT、 フォーミュラ、 ハイブリッドのいずれのポジションであっても、 あらゆるサイズのユーザーに最適です。 フレーム 41 - 画像を参照してください。 バットキッカー マウントの取り付け穴を、 手順 22 で取り付けた T ナットに合わせます。 部品: バットキッカー ポール x 1、 M8 16 mm ボルト x 2、 M8 ワッシャー x 2。...
Seite 40
• 水平な面にコックピットをレイアウトして組み立てます。 80 - 画像を参照してください。 A) シート ブラケットをシート スライダー メンバーに固定している 4 x M8 ボルトとワッシャーを取り外します。 B) シートブラケットを取り外します。 • F-GT Elite 160 は 2 人で組み立てます。 81 - 画像を参照してください。 A) シート スライダー タブを左右のベース メンバーに固定している 4 つのラチェット ハンドルを取り外します。 B) シート スライダー アセンブリを取り外します。 • 部品を無理に組み立てないでください。...
Seite 41
41 - Consulte a imagem. Alinhe os orifícios de montagem no suporte Buttkicker com as porcas em T previamente instaladas na etapa 22. Peças: 1 x poste Buttkicker, 2 x parafusos M8 16mm, 2 x arruelas M8. O F-GT Elite 160 é totalmente ajustável a partir de quase todos os pontos de fixação, tornando-o ótimo para usuários de todos os tamanhos, seja na posição GT, Fórmula ou Híbrida. Use o nível fornecido junto 42 - Consulte a imagem.
Seite 42
79 - Consulte a imagem. Aparafuse e prenda com 3 x parafusos escareados M8. Repita do outro lado. Peças: 6 x parafusos escareados M8. • O F-GT Elite 160 é uma construção para 2 pessoas. 80 - Consulte a imagem. A) Desinstale 4 parafusos e arruelas M8 que prendem os suportes do assento aos membros deslizantes do assento. B) Remova os suportes do assento.
Seite 43
39 - См. изображение. Совместите монтажные отверстия или прорези на пластине переключателя с Т-образными гайками, ранее установленными в шаге 35. Детали: пластина переключателя — 1 шт. F-GT Elite 160 полностью регулируется практически в каждой точке крепления, что делает его идеальным для пользователей любого роста, будь то в положении GT, Formula или Hybrid. Используйте уровень...
Seite 44
80 - См. изображение. A) Удалите 4 болта M8 и шайбы, которыми кронштейны сиденья крепятся к ползунам сиденья. Б) Снимите кронштейны сиденья. • F-GT Elite 160 рассчитан на двух человек. 81 - См. изображение. A) Снимите 4 ручки с храповым механизмом, крепящие выступы ползуна сиденья к правому и левому элементам основания. B) Снимите узлы слайдера сиденья.
Seite 45
39 - Resme bakın. Kaydırıcı Plaka üzerindeki montaj deliklerini veya yuvalarını, Adım 35’te önceden takılmış olan T-Somunlarla hizalayın. Parçalar: 1 x Kaydırıcı Plakası. F-GT Elite 160, GT, Formula veya Hybrid konumunda olsun, hemen hemen her bağlantı noktasından tamamen ayarlanabilir, bu da onu her boyuttaki kullanıcılar için harika 40 - Resme bakın.
Seite 46
81 - resme bakın. A) Koltuk Kaydırıcı Tırnaklarını Sağ ve Sol Taban Üyelerine sabitleyen 4 x Cırcır Kolunu çıkarın. B) Koltuk Kaydırıcı tertibatlarını çıkarın. • F-GT Elite 160, 2 kişilik bir yapıdır. 82 - resme bakın. A) Sol ve Sağ Taban Üyelerinin arkasındaki Uç Kapakları çıkarın. B) Sol ve Sağ Taban Elemanlarının üst kanalına 2 x T-Somun takın. C) 2 x Uç Kapaklarını...
Seite 47
38 - Viz obrázek. NASTAVENÍ RAMENA ŘAZENÍ (Zrcátko pro řadicí páku na pravé straně Uvolněte šrouby zajišťující konzoly ramena řazení ke svislému sloupku a podpěře ramena řazení. F-GT Elite 160 je plně nastavitelný z téměř každého upevňovacího bodu, takže je skvělý pro všechny velké uživatele, ať už jde o polohu GT, Formule nebo Hybrid. Použijte dodanou Nastavte na požadovanou výšku a utáhněte šrouby, aby zapadly na místo.
Seite 48
79 - Viz obrázek. Prošroubujte a zajistěte pomocí 3 x M8 zápustných šroubů. Opakujte na druhou stranu. Díly: 6 x M8 šrouby se zápustnou hlavou. • F-GT Elite 160 je sestaven pro 2 osoby. 80 - Viz obrázek. A) Odinstalujte 4 šrouby a podložky M8 zajišťující držáky sedadel k členům jezdců sedadel. B) Demontujte držáky sedadel.
Seite 49
40 - Patrz zdjęcie. Przykręć i zabezpiecz za pomocą 4 śrub i podkładek M8. Części: 4 x śruby M8 16mm, 4 x podkładki M8. F-GT Elite 160 można w pełni regulować z niemal każdego punktu mocowania, dzięki czemu doskonale nadaje się dla wszystkich użytkowników, niezależnie od tego, czy są w pozycji GT, Formula czy Hybrid. Użyj 41 - Patrz zdjęcie.
Seite 50
Motion z otworami montażowymi NLR Motion V3. Części: 2 x wsporniki ruchu. • F-GT Elite 160 to konstrukcja 2-osobowa. 79 - Patrz zdjęcie. Przykręć i zabezpiecz za pomocą 3 śrub z łbem stożkowym M8. Powtórz po drugiej stronie. Części: 6 x śruby z łbem stożkowym M8.
