5 Device Operation
5.4 Hand Applicator
The hand applicator consists of the following parts:
Hand Applicator (Exploded View)
The oscillator head is screwed into the handle. To remove the head from the applicator handhold, you
have to rotate it to the left.
Important
Any damage to the oscillator membrane might lead to harmless (but unpleasant) sensations
on the skin.
Replace the membrane immediately if damaged.
Replace the membrane after each person to be massaged.
How to Replace the Membrane
(1) Take off the clamping ring and remove the membrane.
(2) Insert the new membrane with the foil facing down loosely into the clamping ring, so that the mem-
brane foil protrudes laterally.
Changing the Membrane - Inserting
®
DEEP OSCILLATION Personal
(1) Applicator handhold (Ref. No. 00379)
(2) Cover
(3) Oscillator Plate
(4) Membrane
(5) Clamp Ring
NOTICE
(2) - (5) make up the oscillator head in the re-
spective size.
