Parts list Folkeboot 1:7,6
Part no.
Description
Stage 1, Boat Stand
1.1
Stand base
1.2
Front support
1.3
Rear support
1.4
Reinforcement
1.5
Reinforcement
Stage 1, Slipway
H1
Slipway side
H2
Slipway rear
H3
Slipway bow
H4
Slipway support
Stage 2, Hull
2.1
Keel sole
2.2
Bow stem
2.3
Rear stem
2.4
Front keel bolt doubling
2.5
Front keel bolt doubling
2.6
Rear keel bolt doubling
2.7
Rear keel bolt doubling
2.8 ‐ 2.21  Frame 1 ‐ Frame 14
2.22
Rear bulkhead
2.23
Keelson
2.24
Bow stem
2.25
Rear stem
2.26
Hull plank 1
2.27‐2.30  Hull plank 2 ‐ 5
2.31‐2.41  Hull plank 6  ‐ 16
2.42
Transom
2.43
Stringer
2.44
Clamp
2.45
Deck beam
2.46
Reinforcement bow
2.47
Reinforcement shrouds doubling
2.48
Reinforcement shrouds below
2.49
Deck frame rear
2.50
Support
2.51
Cabin support
2.52
Clamp cabin/cockpit
2.53
Mast base
2.54
Mast bearing
2.55
Support
2.56
Bowden cable rudder
2.57
Bowden cable bearing
2.58
Forestay fitting
Status October 2024
Material
Plywood 5
Plywood 5
Plywood 5
Plywood 5
Plywood 5
Plywood 3
Plywood 3
Plywood 3
Plywood 3
Plywood 5
Plywood 5
Plywood 5
Plywood 3
Plywood 1
Plywood 3
Plywood 1
Plywood 3
Plywood 3
Plywood 3
Lime strip
Lime strip
Plywood 1,5
Plywood 1,5
Plywood 1,5
Plywood 1,5
Pine
Pine
Pine
Pine
Plywood 5
Plywood 5
Plywood 3
Plywood 3
Pine
Pine
Plywood 5
Plywood 3
Plywood 3
Finished part
3D print part
Brass
Seite 31
Note
Laser sheet 1
Laser sheet 1
Laser sheet 1
Laser sheet 1
Laser sheet 1
Laser sheet 3
Laser sheet 5
Laser sheet 3
Laser sheet 5
Laser sheet 2
Laser sheet 2
Laser sheet 2
Laser sheet 4
Laser sheet 15
Laser sheet 4
Laser sheet 15
Laser sheet 3‐5
Laser sheet 3
Laser sheet 3
5 x 1,5 x 400
5 x 1,5 x 250
Laser sheet 11
Laser sheet 8
Laser sheet 6 ‐ 7
Laser sheet 13
2 x 2 x 1000
5 x 5 x 1050
3 x 5 x 350
5 x 5 x 62
Laser sheet 1
Laser sheet 1
Laser sheet 5
Laser sheet 4
5 x 5 x 300
3 x 5 x 600
Laser sheet 1
Laser sheet 4
Laser sheet 4
D 3 x 600
12 x 1 x 30
©
