If mains supply is present and voltage and frequency are within
•
the range, the built-in stabiliser featuring buck-boost tech-
nology powers the loads.
Compatibility with APFC loads.
•
The vast majority of power supplies for electronic devices
are switched-mode (SMPS) and they are increasingly being
equipped with active power factor correction (APFC) to mini-
mise distortion caused to the electrical line. SPS ADVANCE
UPSs are compatible with all devices that incorporate these
functionalities.
Possibility of fast and easy backup extension by adding battery
•
(1)
modules .
Availability of additional battery chargers to reduce battery
•
recharge time (B1)
Intelligent battery management technology is very useful for
•
extending the life of accumulators and optimising recharge
times.
Control panel with LCD display available on all models.
•
Remote emergency power off control (EPO).
•
Serial communication port: RS232 and USB.
•
Availability of optional connectability cards to improve commu-
•
nication capabilities.
Protection against overload, short circuit and overtemperature.
•
Only in SPS ADVANCE T models.
(1)
Model
SPS 750 ADV R2
SPS 1000 ADV R2
SPS 1500 ADV R2
Tab. 1. SPS ADVANCE R2 standardised models.
Model
SPS 850 ADV T
SPS 1000 ADV T
SPS 1500 ADV T
SPS 2000 ADV T
SPS 3000 ADV T
SPS 1000 ADV T (B1)
SPS 1500 ADV T (B1)
SPS 2000 ADV T (B1)
SPS 3000 ADV T (B1)
Tab. 2. SPS ADVANCE T standardised models.
42
(1) .
Type Input/output type
Single-phase / Single-phase.
Type Input/output type
Single-phase / Single-phase.
4.4. OPTIONAL EXTRAS.
Depending on the configuration chosen, the device may include
any of the following options:

4.4.1. Isolation transformer:

The isolation transformer provides galvanic isolation in order to
completely isolate the output from the input and/or change neutral
mode.
The placement of an electrostatic screen between the primary
and secondary windings of the transformer provides a high level of
electrical noise attenuation.
The isolation transformer can be physically placed at the input or
output of the UPS depending on the technical conditions of the
whole system (device supply voltage and/or load voltage, charac-
teristics or their type, etc.).
In any event, it will always be supplied as a peripheral component
external to the device itself in a separate box.
4.4.2. Communication card.
The UPS features a slot at the rear for inserting one of the fol-
lowing communication cards.
4.4.2.1. Integration into computer networks using
an SNMP adapter.
Large computer systems based on LANs and WANs that integrate
servers in different operating systems must provide the system
manager with ease of control and administration. This facility is
obtained through an SNMP adapter, which is universally supported
by the main software and hardware manufacturers.
Connection of the UPS to the SNMP is internal while that of the
SNMP to the computer network is made through a RJ45 10 base
connector.
4.4.3. Extendable guide kits for mounting in a rack
cabinet (only in SPS ADVANCE R2 models).
An extendable and unique guide kit is available for all SPS
ADVANCE R2 device models, valid for any kind of rack-type
cabinet.
