5. UNIT / FRAME
Check the unit for required replacement (see attachment D)
5.0
Check the unit frame for damages
5.1
Check batteries support for damages
5.2
5.3 Check the fixation of the strap/bracket on the batteries
Check torque on bolts (backside of unit) (14Nm | 124 Lb-In)
5.4
Check the brushes on the power pack for damages
5.5
Clean the space around rollers and bearings and remove all dirt
5.6
Check rollers and bearings for wear
5.7
Check if rollers and bearings run smoothly
5.8
Check the charging springs for shape, wear and functionality (spring force)
5.9
Check the shape of activation rods
5.10
Check if activation rods move smoothly and activate the switches of the print circuit board
5.11
Check the fixation of the adaptor plates
5.12
Check the print circuit board for damages
5.13
Check the function of the final limit switches in the unit
5.14
5.15 Clean the brushes on the power pack
Cleck if the wheelset plate is damaged. Replace the plate when damaged (see instruction AA27797)
5.16
6. WIRING
Check the wiring for damages
6.0
Check if the wiring is fitted correctly
6.1
Check the earth wire connections on the frame, unit and rail
6.2
7.CHAIR
Check the presence of the CE sticker
7.0
Check the chair for damages
7.1
Check for too much noise
7.2
Check the armrest and the armrest hinge for damages
7.3
7.4 Check the function of the joystick and for damages
Check the function of the keyswitch and the presence of the spare key
7.5
Check the fixation of the safety belt bracket and function of the safety belt
7.6
Check the mechanical lock of the seat
7.7
Check the footrest for damages
7.8
7.9 Check the fixation of the footrest
Check presence and fixation of the bolts and securing bolt under the seat
7.10
Check the fixation of the chair
7.11
Check all welding of the chair frame pivot
7.12
Check the perpendicularity of the chair with a spirit level
7.13
Check functionality of the armrest switches
7.14
Check functionality of the stop button
7.15
Check accuracy of the joystick
7.16
Check the function of the chair support detection switch
7.17
Check the chairsupport detection is less than 50 N in the up direction
7.18
Check the function of all cover detectionswitches
7.19
Check the cover detection is less than 50 N in both directions
7.20
Check the function of all footrest detection switches
7.21
Check the footrest detection is less than 30 N in 3 directions
7.22
Check the function of the chairposition switch under the seat
7.23
Check the function of the final limit switches
7.24
Check for charging problems
7.25
If installed check functionality of the OneTouchAssist
7.26
For examination ot this section reinstall all removed parts of the lift
