Operating Concept
4.5
Conformity-assessed Devices
Display
2
Fig. 8: Weighing range display for conformity-assessed devices
(example)
Pos .
Name
Description
1
Labeled
Labels the differentiated
points
points.
2
Model-
Optional display
specific
information
14
Entris
II Advanced Line Operating Instructions
®
4.6
The buttons on the device may have different statuses.
The principle is explained with the following example:
1
Symbol
Status Display of the Buttons
Name
Description
Button
The button is highlighted
enabled
orange. Pressing the
button opens a menu, for
example.
Inactive
The button is highlighted
button
white. No action, e.g.,
toggle between weight
units, can be carried out.
